PRESCRIPTION
VINCENT 316-2
Street retro imitation style, one-piece arc outer panel, rounded rearview mirror, concave-shaped seat cushion, split handle, classic "XO" headlight design, continue the retro spirit, and pay tribute to the sports car style of the 1990 s. Low-pressure sand core casting double-wing beam aluminum alloy frame, the whole vehicle line is full, low lying fighting posture is full of strength. Equipped with a 500CC water-cooled two-cylinder in-line engine, the maximum speed can reach 190 KM/H, the wild core has ample power output, and can run efficiently for a long time.
Key words:
Classification:
Two-wheeler
Riding bike
Hotline:
VINCENT 316-2
Graphic Details
Product Parameters
| No. | ZFR525C | ||||
| Model | Avengers | ||||
| Engine | Engine type | Two-cylinder, four-stroke, water-cooled, vertical | Body | Frame type | Double-wing beam aluminum alloy frame |
| Cylinder diameter × stroke (mm) | 68*68 | Length * width * height (mm) | 2050*800*1150 | ||
| Displacement (ml) | 500 | Seat height (mm) | 810/830 | ||
| Compression ratio | 11.5:1 | Ground clearance (mm) | 142 | ||
| Peak power (kw/r/min) | 39/8500 | Wheelbase (mm) | 1440 | ||
| Peak torque (Nm/r/min) | 50/6500 | No-load mass (KG) | 185 | ||
| Oil supply mode | EFI | Fuel tank capacity (L) | 15 | ||
| Fuel consumption | 3.6L/100km | Appearance color selection | Ice white, track blue, retro red | ||
| Maximum design speed | ≤ 190(km/h) | Wheels and tires | Front brake system | Double disc to four piston radial caliper | |
| Manipulation | Start mode | Electric start | Rear Brake System | double-piston caliper | |
| Clutch form | wet multi-plate sliding clutch | Tire specifications | Front: 120/70-17, Rear: 160/60-17 | ||
| Gearbox form | International 6 | Brake type | Front disc/rear disc | ||
| ABS device | Yes | ||||
Product display
1. The 500CC water-cooled two-cylinder in-line engine has a maximum power of 39kW/8500pm and a maximum torque of 50N.m/6500rpm. It has abundant power output and can run at high speed for a long time.
2. The front double disc brake system and the rear large single disc brake system, with the dual-channel ABS brake system, have superior braking performance and give the rider the greatest sense of security.
3. Pre-pressure adjustable inverted shock absorption and rear oil pressure adjustable shock absorption system provide vehicle handling performance and ultimate driving experience.
4. Equipped with TFT color display, clear visual effects and diversified functions. "XO" round LED headlamps with circular arc outer plate, personality modeling let you become a bright spot on the street.
Company Department Introduction
Professional enterprise team, complete production process
Multiple departments supervise each other and standardize the production process to ensure that customer requirements and relevant quality standards are met
Research and Development Department:
Responsible for the development of product inspection standards.
Quality Control Department
Responsible for product inspection, production process and regular inspection of final products
Production workshop
Responsible for self-inspection and mutual inspection of production process.
Optimize supply chain management
We can help customers optimize supply chain management, provide supply chain coordination, logistics and distribution services, ensure stable product supply and reduce costs.
Why choose us?
Company advantage
Changhua Group is a professional OEM and ODM motorcycle factory. Our company has middle and senior technical personnel and management personnel, and employs technical experts, management and marketing elites in the domestic industry. In order to realize the sustainable development of enterprises, we have invested a lot of money in research and development to explore new technologies and new materials. At present, we have obtained 35 patented designs and developed a series of motorcycles with independent intellectual property rights.
Service advantage
We have a dedicated service team docking customers, can timely solve the customer pre-sale, sale, after-sales needs. Changhua Group is willing to accompany customers to grow together and solve problems for customers with fast and effective service. We will continue to maintain our business purpose: customer quality requirements, is our work standard.
ISO 9001
CQC
CE
