Eagle Thirteen CH150T-3F3
Fashion sports scooter, combined with eagle eye design LED headlights, to create a sports exquisite appearance. Equipped with a reliable 150CC air-cooled engine, it provides smooth acceleration while bringing amazing fuel economy. Lightweight design body, equipped with high rigidity frame and excellent suspension system, smooth straight running and flexible operation. The large-capacity storage space under the seat bag, open front storage box, and optional large rear tail box make it easy to carry your necessities, making every ride a practical and pleasant experience.
Key words:
Classification:
Scooter
Hotline:
Eagle Thirteen CH150T-3F3
Graphic Details
Product Parameters
| No. | CH150T-03F3 | ||||
| Model | Eagle Thirteen CH150T-03F3 | Optional body color | Red/Black/White/Blue/Customized | ||
| Engine | Engine type | GY6-150CC, air-cooled | Body | Length * width * height (mm) | 1825 × 645 × 1100 |
| Cylinder diameter x stroke (mm) | 57.4 × 57.8 | Seat height (mm) | 720 | ||
| Displacement (ml) | 150 | Ground clearance (mm) | 110 | ||
| Compression ratio | 9.8:1 | Wheelbase (mm) | 1230 | ||
| Peak power (kw/r/min) | 6.3 | curb weight (KG) | 97 | ||
| Peak torque (Nm/r/min) | 9 | Fuel tank capacity (L) | 4.5 | ||
| Start mode | Electric/foot start | Tire specifications | Front 90/90-10 Rear 3.50-10 | ||
| Maximum design speed | ≤85 | Brake type | Front Disc Rear Drum | ||
Product display
1. Equipped with 150CC air-cooled engine, it provides stable power while reducing fuel consumption, and emissions are more environmentally friendly. Lightweight body design, with powerful single disc brakes, easy to cross urban roads.
2. Equipped with LED headlights, the light source is concentrated, has penetrating power, and shines to a wider place.
3. The mechanical instrument panel is stylish and concise, and sensitively displays the information and status of the scooter.
4. The ergonomically designed seat bag is spacious and comfortable, and the double ride also has good comfort. It is a good helper for family sharing.
Company Department Introduction
Professional enterprise team, complete production process
Multiple departments supervise each other and standardize the production process to ensure that customer requirements and relevant quality standards are met
R & D Dept:
Responsible for the development of product inspection standards.
Quality Control Department
Responsible for product inspection, production process and regular inspection of final products
Production workshop
Responsible for self-inspection and mutual inspection of production process.
Optimize supply chain management
We can help customers optimize supply chain management, provide supply chain coordination, logistics and distribution services, ensure stable product supply and reduce costs.
Why choose us?
Company advantage
Changhua Group is a professional OEM and ODM motorcycle factory. Our company has middle and senior technical personnel and management personnel, and employs technical experts, management and marketing elites in the domestic industry. In order to realize the sustainable development of enterprises, we have invested a lot of money in research and development to explore new technologies and new materials. At present, we have obtained 35 patented designs and developed a series of motorcycles with independent intellectual property rights.
Service advantage
We have a dedicated service team docking customers, can timely solve the customer pre-sale, sale, after-sales needs. Changhua Group is willing to accompany customers to grow together and solve problems for customers with fast and effective service. We will continue to maintain our business purpose: customer quality requirements, is our work standard.
ISO 9001
CQC
CE
